TI Sitara™ AM3352 ARM-based Industrial IoT Gateway with Dual LAN and Pre-installed Debian.

  • Industrial grade ARM-based system with pre-installed Debian
  • AWS Device Qualification Program (DQP) Certified
  • Certified to operate on Verizon network
  • Field-ready Isolated DI/O and RS-232/422/485
  • 10 to 25V wide-range DC input and 802.3at PoE+ PD
  • -25°C to 70°C wide temperature operation

Aplicación: Industrial / IOT

Ref. Cenval: OEM-R09xx

Tipo: Industrial IOT

12-24 volts   -25º a 70º   Debian

0,00 €

Intel® Atom™ Bay Trail in-vehicle fanless embedded computer with 2x IEEE 802.3at PoE+ ports.

- Intel® Atom™ Bay Trail E3845 quad-core processor
- Dual mPCIe and USIM sockets for 3G, LTE, WLAN, BT or GPS modules
- Dual storage with 1x mSATA and 1x SATA
- Intelligent ignition power control
- 1x CAN bus port with compliance to CAN bus 2.0A and CAN 2.0B
- 8 to 35VDC wide-range DC input
- Operating temperature from -25° to 70°C
- Patented damping bracket for in-vehicle installation (R.O.C Patent No.M491752)
- E-Mark certificate (E13 No. 10R-0513905)

Aplicación: Industrial / Transporte
Ref. Cenval: OEM-C0904xxx
Tipo: In-vehicle computing



0,00 €

Intel® 9th/ 8th-Gen Core™ i7/i5/i3 in-vehicle fanless embedded computer in EN50155 certification with 4x M12 PoE+ ports, DIO, CAN bus and RAID.

-  Supports Intel® 9th/ 8th-Gen Core™ i7/i5/i3 LGA1151 socket-type CPU
-  4x or 8x 802.3at Gigabit PoE+ ports via M12 or RJ45 connectors
-  On-board isolated CAN bus for in-vehicle communication
-  4-CH isolated DI and 4-CH isolated DO
-  2x SATA ports with one hot-swappable HDD tray, supporting RAID 0/1
-  2x M.2 B key and 3x full-size mini-PCIe sockets
-  8~35V wide-range DC input with built-in ignition power control
-  E-Mark and EN 50155 certificate

Aplicación: Industrial / Ferroviaria / Transporte
Ref. Cenval: OEM-C0904xxx
Tipo: In-vehicle computing

               Intel Core

0,00 €

Intel® 6th-Gen Core™ i7/i5/i3 fanless rugged embedded computer with 6x GbE, expansion cassette & MezIO™ interface.

  • Supports Intel® 6th Gen Core™ i7/i5/i3 35W/65W LGA1151 CPU
  • Patented Cassette for PCI/PCIe add-on card accommodation (* R.O.C Patent No. M456527)
  • MezIO™ interface for easy function expansion
  • Rugged, wide temperature range from -25°C to 70°C fanless operation
  • Up to 6x GigE ports, supporting 9.5 KB jumbo frame
  • Up to 32 GB, DDR4-2133 SODIMM
  • Accommodates two 2.5" SATA HDD/SSD with RAID 0/1
  • VGA/DVI/DP triple independent display, supporting 4K2K

Aplicación: Industrial / Vision / Comunicación
Tipo: Rugged embedded

0,00 €

Intel® 6th-Gen Core™ i7/i5/i3 Skylake in-vehicle fanless embedded computer with 4x PoE+ Ports, DIO, CAN bus and RAID.

- Supports Intel® 6th-Gen Core™ i7/i5/i3 LGA1151 socket-type CPU
- Up to 4x 802.3at Gigabit PoE+ ports via RJ45 connectors
- On-board CAN bus for in-vehicle communication
- 4-CH isolated DI and 4-CH isolated DO
- 2x SATA ports with one hot-swappable HDD tray, supporting RAID 0/1
- 4x full-size mini-PCIe sockets with SIM support
- 8V to 35V wide-range DC input with built-in ignition power control
- EN 50155/ EN45545 certificate & E13 No. 10R-0514321



0,00 €

Intel® 9th/ 8th-Gen Core™ i7/i5/i3 fanless rugged embedded computer with 6x GbE, patented cassette & MezIO™ interface.

  • Intel® 9th/ 8th-Gen Core™ i 35W/ 65W LGA1151 CPU
  • Patented Cassette for PCI/PCIe add-on card accommodation
  • MezIO™ interface for easy function expansion
  • Rugged, wide temperature range from -25°C to 70°C fanless operation
  • Up to 6x GigE ports, supporting 9.5 KB jumbo frame
  • M.2 2280 M key socket (Gen3 x4) supporting NVMe SSD or Intel® Optane™ memory
  • 4x USB 3.1 Gen2 ports and 4x USB 3.1 Gen1 ports
  • VGA/ DVI/ DP triple independent display, supporting 4K2K resolution

Aplicación: Industrial / Comunicación / Vision
Ref. Cenval: OEM-A09xx
Tipo: Rugged embedded

 Fanless

0,00 €

Intel® 9th/ 8th-Gen Core™ i7/i5/i3 fanless rugged embedded computer with 6xGbE, MezIO™ interface & low-profile chassis.

  • Intel® 9th/ 8th-Gen Core™ i 35W/ 65W LGA1151 CPU
  • Low-profile chassis with hot-swappable 2.5" HDD/ SSD tray
  • MezIO™ interface for easy function expansion
  • Rugged, wide temperature range from -25°C to 70°C fanless operation
  • Up to 6x GigE ports, supporting 9.5 KB jumbo frame
  • M.2 2280 M key socket (Gen3 x4) supporting NVMe SSD or Intel® Optane™ memory
  • 4x USB 3.1 Gen2 ports and 4x USB 3.1 Gen1 ports
  • VGA/DVI/DP triple independent display, supporting 4K2K resolution

Aplicación: Industrial / Comunicación / Visión artificial
Tipo: Rugged embeddedNUVO-7006LP Nuvo-7002LP

          E511815

0,00 €

- Intel® Apollo Lake Pentium® N4200 and Atom™ E3950 quad-core processor
- Fanless and rugged, wide temperature operation (-25 °C to 70 °C)
- One GbE port and two Gigabit PoE+ ports
- Two USB 3.1 Gen1 and two USB 2.0 ports
- DVI + VGA dual display outputs
- Front I/O access DIN-mounting design
- MezIO™ compatible

Aplicación: Industrial / Comunicación
Ref. Cenval: OEM-A09xx
Tipo: Rugged computer



0,00 €

Intel® Atom™ E3950 Apollo Lake ultra-compact fanless in-vehicle communication gateway controller with GbE, PoE+ & Isolated CAN.

- Intel® Apollo Lake Atom™ E3950 quad-core processor
- Rugged, -25 °C to 70 °C fanless operation
- Two IEEE 802.3at PoE+ ports and one GbE port
- One isolated CAN port for in-vehicle communication
- One M.2 socket and three mini-PCIe sockets
- Aluminum heat-spreader for M.2/ mPCIe modules
- 4-CH isolated DI and 4-CH isolated DO
- 8~35V DC input with built-in ignition power control

Aplicación: Industrial / Ferroviaria / transporte
Ref. Cenval: OEM-A09xx
Tipo: In-vehicle computing



0,00 €

PC compacto ARM con procesador NXP i.MX8M Mini Quad-Core 1.6 GHz ARMCortex-A53 de 1,6 GHz, sin ventilador, opera en rango de temperatura 0 a +60º (opcional -40 a +80 °C) y ofrece opciones de montaje VESA y carril DIN (opcional).

NXP i.MX8M Mini-1.6GHz

1GB / 2GB / 4GB
RS-232 / RS-485
USB / GLAN / Audio
HDMI / 12V~36v

0,00 €

Industry first 5G enabled embedded Industrial system with Intel® Core™ i3-7100U Processor/ Din Rail/ 2 side aluminum

- System Size : 160W x 118D x 62.6H(mm)
- Intel® Core™ i3-7100U Processor
- Dual Channel DDR4, 2 x SO-DIMMs
- HDMI, Display port for Dual display
- 2 x GbE LAN Ports
- 5G module support

Aplicación:
Industrial Automation
Factory Automation
HMI
Embedded & Industrial Applications
DVR / Surveillance

Intel Core 2,5" M2 Display Port 3G Wide DC in  Fanless  Rugged IHR Watchdog USB 3.2
